1.0 Background

2.0 Modeling aims and objectives

3.0 Concept model

3.1 Additional figures

There are several components that affect hemoglobin during pregnancy, including in multiplicative (for the hemoglobin pregnancy adjustment factor) and additive (for the antenatal supplementation, antenatal IV iron, and postpartum IV iron interventions as well as maternal hemorrhage risk effects) manners. The figures below visually represent these changes.

Note

The depiction above does not represent hemoglobin exposure value changes due to changing age groups, which will happen in the vivarium simulation. The following figure shows how changing age groups may change simulant hemoglobin exposure.

3.2 Simulation timeframe and intervention start dates

Note

The simulation timestep is documented to be two weeks in these tables, but as of 5/17/2021 it is set to one week and has not yet been updated to two.

Throughout model development and verification/validation prior to intervention implementation:

Developmental model maternal simulation timeframe and intervention dates

Parameter	Value
Date of simulation burn-in period start	N/A (no burn-in)
Date of simulation observation period start	January 1, 2022
Date of intervention scale-up start	Janary 1, 2023
Date of simulation end	December 31, 2024
Simulation time step	2 weeks
Intervention scale-up rate	Immediate jump to target coverage level

Throughout model development and verification/validation with intervention implementation:

Developmental model maternal simulation timeframe and intervention dates

Parameter	Value
Date of simulation burn-in period start	N/A (no burn-in)
Date of simulation observation period start	January 1, 2022
Date of intervention scale-up start	Janary 1, 2023
Date of simulation end	December 31, 2027
Simulation time step	2 weeks
Intervention scale-up rate	Same scale-up pace as the .csv file on the IV iron simulation landing page over the four-year scale-up and then held constant at maximum coverage value for one year.

For final model results:

Final model maternal simulation timeframe and intervention dates

Parameter	Value
Date of simulation burn-in period start	January 1, 2019 (note: 1 year burn-in to initialize pregnancy, five year burn-in to initialize child population)
Date of simulation observation period start	January 1, 2025 (NOTE: child outcomes should be tracked starting January 1, 2020)
Date of intervention scale-up start	Janary 1, 2025
Date of simulation end	December 31, 2039
Simulation time step	2 weeks
Intervention scale-up rate	See the .csv file on the IV iron simulation landing page

4.0 Vivarium modelling components

4.1 Vivarium concept model diagram components

4.1.1 Cause Models

• Maternal disorders

• Maternal hemorrhage incidence

• Postpartum depression

4.1.2 Joint Cause-Risk Models

• Hemoglobin, anemia, and iron deficiency model

Including,

• Hemoglobin exposure model

• Anemia impairment model

Todo

Detail strategy for accruing anemia YLDs that is compatible with the strategy for accruing maternal disorders YLDs and postpartum depression YLDs.

4.1.3 Risk Exposure Models

• Maternal Body Mass Index conditional on hemoglobin status

• Low Birthweight and Short Gestation (GBD 2019)

Note

These risk exposures will be correlated, as discussed in the risk-risk correlation model section.

4.1.4 Risk Effects Models

• Hemoglobin/Iron deficiency risk effects, including the impact on:

  • Maternal disorders,

  • Maternal hemorrhage incidence,

  • Birth outcomes, and

  • Postpartum depression

• Maternal hemorrhage risk effects

4.1.5 Risk-Risk Correlation Models

• Maternal BMI, maternal hemoglobin, and infant birthweight

4.1.6 Non-standard Models

• Pregnancy model

4.1.7 Intervention Models

Note

Simulants should have the same propensity value for all modeled interventions (if coverage of all modeled interventions is 50%, then the same 50% of simulants will be getting each intevention). Additionally, treatment propensity is fixed throughout the simulation and does not update between multiple pregnancies.

Also, the same propensity should be used for the effect size on of both the antenatal and postpartum IV iron interventions (referenced below) on hemoglobin.

• Maternal supplementation

• Antenatal IV iron

• Postpartum IV iron

4.2 Demographics

Location aggregation

Details on how to calculate weighted averages for specific simulation parameters are shown in the tables below.

Weighted average calculation instructions

Parameter	Parameter ID	Available location IDs	Weighting unit	Age-specific?	Note
Population size	N/A (use get_population)	159, 166, 44577, 44578	N/A	Yes
Age-specific fertility rate (ASFR)	covariate_id 13	159, 166 (not available for 44577 or 44578)	WRA	Yes
Cause and sequela data	c366, c367, s182, s183, s184	159, 166, 44577, 44578	PLW	Yes
Hemoglobin modelable entity IDs	MEIDs 10487 and 10488	159, 166 (not available for 44577 or 44578)	CUSTOM (see below)	No
BMI modelable entity IDs	MEIDs 2548 and 18706	159, 166 (not available for 44577 or 44578)	WRA	Yes	Parameter not currently incorporated into maternal BMI exposure model
Stillbirth to live birth ratio (SBR)	covariate ID 2267	None (national only)	ASFR \(\times\) WRA	No
Antenatal care visit attendance (ANC)	covariate ID 7	None (national only)	PLW	No
In-facility delivery proportion (IFD)	covariate ID 51	None (national only)	PLW	No
Maternal low BMI exposure	covariate ID 1253	None (national only)	PLW	No	Current covariate for BMI exposure model, but may eventually be updated.
Anemia impariment	REIDs 192, 205, 206, 207	159, 166, 44577 and 44578	WRA	Yes	Parameter used for validation, but not for model building
LBWSG exposure at birth among males	REI ID 339, sex_id=1, age_group_id=164	159, 166 (not available for 44577 or 44578)	ASFR \(\times\) WRA \(\times\) male_sex_ratio	No	Weight each exposure category prevalence separately
LBWSG exposure at birth among females	REI ID 339, sex_id=2, age_group_id=164	159, 166 (not available for 44577 or 44578)	ASFR \(\times\) WRA \(\times\) (1 - male_sex_ratio)	No	Weight each exposure category prevalence separately

Where,

Parameter values for weighted average calculations

Parameter	Description	Value	Note
WRA	National population size of women of reproductive age (ages 10 to 54)	get_population, decomp_step=’step4’, age_group_id=[7,8,9,10,11,12,13,14,15], sex_id=2	Either age-specific or summed across age groups if not age-specific
PLW	National number of women who become pregnant within one year	WRA \(\times\) (ASFR + (ASFR * SBR) + incidence_c996 + incidence_c374)	Calculate at the age-specific level and sum the result across age groups if not age-specific
ASFR	Age-specific fertility rate	covariate_id=13, decomp_step=’step4’	For use in weighting – either: [1] Assume normal distribution of uncertainty truncated at [0,1] and sample draw-level values for each location using different random seeds, or [2] use the mean_value point estimate
SBR	Stillbirth to live birth ratio	covariate_id=2267, decomp_step=’step4’	Not age-specific; no uncertainty
incidence_c996	Incidence rate of abortion and miscarriage cause	cause_id=996, source=como, decomp_step=’step5’, measure_id=6
incidence_c374	Incidence rate of ectopic pregnancy	cause_id=374, source=como, decomp_step=’step5’, measure_id=6
male_sex_ratio	Ratio of male births to all live births	Defined for each modeled location on the pregnancy model document

Hemoglobin distribution weighting strategy

For the continuous hemoglobin distribution parameters, rather than population-weight the mean and standard deviation of the continuous distribution and then sample from those summary statistics, we will instead sample individual simulant hemoglobin exposures from the national-level distributions with a probability equal to the population weight of that nation within the modeled region among the age-specific population size of women of reproductive age (WRA).

Specifically, at the simulant level, the country from which the hemoglobin exposure is sampled should be determined at initialization or entrance into the simulation and should not change for the duration of the simulation. Notably, although simulants’ sampling country and hemoglobin exposure propensities will not change throughout the simulation, their hemoglobin exposure values may change as they progress to the next age group (as described in the hemoglobin document). The sampling probabilities for each country within the modeled regions are defined below.

Probability of sampling from a given country’s hemoglobin distribution using the mean and standard deviation hemoglobin parameters for that country:

\[\frac{population_\text{country}}{population_\text{region}}\]

Parameter definitions for hemoglobin distribution weighting

Parameter	Definition	Value	Note
\(population_\text{country}\)	Age-specific population size of women of reproductive age for a given national location	See definition of WRA in table above	Summed across all age groups
\(population_\text{region}\)	Age-specific population size of women of reproductive age for a given regional location	\(\sum_{country=1}^{n} population_\text{country}\)	For all countries within the region

Note

We may update the weighting unit to pregnant and lactating women (PLW) rather than WRA once we have confirmed that our hemoglobin exposure model is functioning properly by validating to GBD. Although the hemoglobin exposure distribution is specific to women of reproductive age, we have chosen to weight the hemoglobin exposure distribution to the population size of pregnant and lactating women due to our explicit project focus on PLW. This prioritization of hemoglobin exposures among PLW may cause slight differences in our location-aggregated estimates of anemia among non-pregnant or postpartum simulants among WRA compared to the regional estimates from GBD.

Although the hemoglobin distribution and population size parameters are age-specific, we will calculate the population weights among PLW overall rather than at the age specific level to allow us to sample from the same national-level distribution for the same simulant as they age so that we can maintain logical hemoglobin exposure trajectories at the simulant level.

4.2.1 Population description

Throughout model development and verification/validation:

Maternal simulation model development population parameters

Parameter	Value	Note
Population size	100,000	per random seed/draw combination
Number of draws	66
Number of random seeds	10	per draw
Cohort type	Closed
Age start	7 years	Minimum age at initialization. Chosen by subtracting number of simulation run years from 10 years of age (minimum fertile age in GBD)
Age end	54 years	Maximum age at initialization
Exit age	57 years (track through the 56th year until the start of the 57th year)	Maximum age of tracking in simulation. Allows capture of potential events for pregnancies that occur at the end of the 54th year, including maximum gestation period and 1 year post-maternal disorder state.
Sex restrictions	Female only

Todo

The GBD defines reproductive age as 10 to 54 years of age. However, many other data sources define reproductive age as 15 to 49 years of age.

We should confirm with the BMGF that they would like to model the GBD definition rather than standard definition from other data sources.

Note

The overall fertility rate among women of reproductive age is 0.055 for South Asia and 0.105 for Sub-Saharan Africa (not including stillbirths). Therefore, approximately these fractions of the total population multiplied by the number of simulation years of WRA will enter the population of interest of PLW in our simulation.

For final model results:

Maternal simulation final model population parameters

Parameter	Value	Note
Population size	10,000	per random seed
Number of draws	50
Number of random seeds	120	per draw
Cohort type	Open
Age start	10	Minimum age at initialization
Age end	57	Maximum age at initialization
Exit age	57
Sex restrictions	Female only

4.3 Models

Model verification and validation tracking

Model	Description	V&V summary
I.0	Demography for Sub-Saharan Africa and South Asia	Notebook for validation can be found here. All-cause mortality rates look good. Age fraction looks reasonable, but slightly off for boundary age groups, likely a result of the assumption of uniform distribution of ages within a five year age group – ok to proceed.
I.1	Pregnancy model for Sub-Saharan Africa and South Asia	Validation notebook can be found here. [1] ASFR covariate has negative values in the youngest age group for some draws… perhaps should update to truncated normal distribution. [2] duration of postpartum period appears to be too long… closer to 7 weeks than 6. [3] Request to have pregnancy person time stratified by pregnancy outcome in order to evaluate approximate differential duration of pregnancy. [4] Request to have all pregnancy transition counts rather than just np->p.
I.2	Maternal disorders	Validation notebooks are available here. [1] mortality rate due to other causes overestimated by a factor of approximately 50 (this is a new problem that was not present in model I.1). [2] seeing age trend in maternal disorders burden attributable to differences bewteen rate of conception and rate of birth within each age group. [3] Underestimating maternal disorders burden relative to GBD overall [4] previous issues appear to remain unresolved.
I.3	Maternal hemorrhage incidence (not yet severity-specific), hemoglobin/anemia exposure model (with known bug in anemia state person time observer)	[1] Overestimation of ACMR from model I.2 now resolved. [2] Overestimation of total maternal disorders burden (underestimation from model I.2 now resolved) [3] Underestimation of maternal hemorrhage incidence. [4] Apparent long duration of no maternal disorders pregnancy state and duration of pregnancy state does not appear to be shorter for “other” pregnancy outcome relative to live and still births. [5] Issue of negative draws for ASFR from previous models now resolved. [6] Mean hemoglobin estimates scaled to week timestep rather than annual. [7] Appear to underestimate pregnancy outcome counts.
I.3updates	Updated hemoglobin weighting from WRA to PLW, fixed birth outcome initialization issue, fixed pregnancy transition from all states issue, fixed some person-time issues.	Notebooks are available here [1] Underestimation of maternal hemorrhage incidence remains (note: does not vary by year so likely not related to intiailization and also the ratio between moderate and severe looks as expected). [2] Hemoglobin/anemia still not totally validating. [3] The following issues were resolved: pregnancy state durations look good, birth outcome rates look good, hemoglobin pregnancy adjustment factor looks good. [4] Birth outcome counts are equal to transitions out of pregnancy state, which is appropriate (need to check and make sure it’s possible for death due to maternal disorders to result in birth outcome!). Ali to investigate hemoglobin and anemia thresholds look as they should in an interactive sim.
I.3 hemorrhage fix	Fixed issues of maternal hemorrhage incidence using GBD incidence rate rather than the probability listed on this page and observers counting multiple outcomes.	Maternal hemorrhage incidence looks good! Now only off by the age-group trend previously identified.
I.3 hemoglobin weighted to single national location	Weighted 100% of simulants to the hemoglobin distributions of Nigeria for the Sub-Saharan Africa location and to Bangladesh for the South Asia location to see if our validation issues were caused by our location aggregation strategy.	Mean hemoglobin is validating well now. Anemia prevalence still very off.
I.3 hemoglobin distribution code update	Updated to mirrored_gumbel_ppf_2017 function	Anemia prevalence is validating!! :) :)
I.3.5.0 code refactor	Refactoring of model by James, need to check nothing broke.	Validation notebooks for model 3.5.0 are available here. Maternal disorders and hemorrhage cause model, hemoglobin/anemia model, and pregnancy model are largely looking good. I noticed the following issues [1] postpartum duration in the outputs looks like it’s just one week even though in the interactive sim it was consistently 5 weeks, [2] I had an issue with my validation code and we are actually not systematically overestimating pregnancy/maternal disorders at the population level, which means that the age shift implementation is not necessarily necessary for success, [3] it looks like the YLDs count data may not be properly stratified by cause… it looks like maternal disorders and anemia YLDs may be combined and labeled as maternal disorders only.
I.3.5.1 code refactor with LBWSG gestational age	LBWSG exposure used to inform duration of pregnancy	Validation notebooks for model 3.5.1 are available here. It appears that the duration of pregnancy, which used to be ~36 weeks, is now ~4 weeks. This is causing us to overestimate pregnancy incidence and outcomes related to it (like maternal disorders).
I.3.5.1: Bugfix and BMI	Fixes to pregnancy state durations and YLDs as well as implementation of BMI/Hemoglobin exposure	Validation notebooks for model 3.5.1_bugfix are available here. Postpartum duration now five weeks as expected. Pregnancy duration approximately equal to mean gestational age, as expected (but can be followed up with a more detailed validation in interactive simulation). YLDs behaving as expected. Joint BMI/hemoglobin exposure functioning as expected (although verification that exposure does not change with intervention scenarios should be done when ready).
I.8 Intervention coverage	Implemented intervention coverage and scenarios	Validation notebook for intervention coverage is available here. Issues added to the table below. BEP/MMS targeting looks good. Rate of scale-up looks good.
I.8 Intervention coverage, bugfix	Run to fix issues identified with the previous run	Validation notebooks for the intervention coverage bugfix run are available here. All issues appear resolved, with the exception of the request for output of intervention administration counts. Also of note, the “antenatal_iv_iron_invalid” and “postpartum_iv_iron_invalid” person time categories are inclusive of simulants with hemoglobin levels greater than 10 g/dL at the time of administration – this makes direct V&V of the intervention targeting difficult, and it should be doublechecked when intervention administration counts are provided as an output and/or in the interactive simulation.
I.8 intervention effects	Implement intervention effects and add intervention administration count outputs.	[1] Deaths due to maternal disorders not equal between baseline and alternative scenarios. Deaths due to other causes vary between all scenarios [2] Anemia YLDs not equal in baseline and alternative scenarios in the not pregnant state. [3] Anemia YLDs not varying by scenario as expected in the pregnant state, even though anemia person time does. [4] Would like hemoglobin sum and person time output files stratified by intervention coverage to verify intervention effect sizes, please. [5] Intervention count outputs and coverage looks good :)
I.8 intervention effects bugfix	Fix results processing and other bugs causing issues from above model version	Results look as expected :). No longer have unexpected differences in scenarios. Intervention effects on hemoglobin look good in the results outputs as well as in the interative sim.
I.5 Hemoglobin effects on maternal disorders	All model 4 risk effects included now	Results look as expected :)
I.8.2 2040 run	Add fertility component, run out to 2040, with risk effects and intervention models	Results ran out to 2040 look as expected :). No longer have unexpected differences in scenarios. Intervention effects on hemoglobin look good in the results outputs as well as in the interative sim.
I.9.1 Stillbirth	Stillbirth implementation	Magnitude of effect by severe anemia status looks good. Appears to result in increases to stillbirth, but not other births (as expected). However, there is a bug that results in all birth outcome counts for “no” anemia to be zero – there should instead be counts for “none” anemia. This prevents us from comparing counts of birth outcomes across scenarios.
I.9.2	Stillbirth bugfix, single draw	There are now birth outcome counts for “none” anemia and differences in birth outcome counts are as expected across scenarios. Good to go!
I.9.3	Ethiopia, Nigeria, and India test runs: baseline scenario only, out to 2030	Hemoglobin, maternal disorders, pregnancy, and intervention coverage models all looking as expected :)

Outstanding verification and validation issues

Issue	Explanation	Action plan	Timeline
Age group issues (underestimation of births in young ages and overestimation in older ages)	Related to start versus end of pregnancy timing	Ticket made	Lower priority – nice to have, but not necessary for success
Hemoglobin exposure summed at the weekly rather than annual level		SWEs to update	Low priority since Ali can adjust for this on the back-end

4.4 Desired outputs

For model version I:

1. DALYs (YLLs and YLDs) due to a) maternal disorders, and b) anemia among a) pregnant, b) postpartum, and c) women of reproductive age

2. Severity-specific anemia prevalence during a) pregnancy, and b) the postpartum period

3. Average hemoglobin level among during a) pregnancy, and b) the postpartum period

4. Numbers of intervention regimens administered per a) 100,000 births, and b) 100,000 person years of women of reproductive age

5. Rates of each pregnancy outcome (live birth, stillbirth, abortion/miscarriage)

4.5 Simulation output table

Maternal simulation output table

Measure	Maternal age/sex/year stratification	Pregnancy state	Pregnancy outcome	Severity-specific maternal hemorrahge incidence	Maternal supplementation coverage	Antenatal IV iron coverage	Postpartum IV iron coverage	Maternal BMI exposure
Pregnancy state transition counts	TRUE	N/A	TRUE	FALSE	TRUE	TRUE	TRUE	FALSE
Pregnancy state person-time	TRUE	N/A	TRUE	FALSE	TRUE	TRUE	TRUE	FALSE
Count of pregnancy outcomes (live, still, other)	TRUE	N/A	N/A	FALSE	TRUE	TRUE	TRUE	FALSE
Deaths (cause-specific)	TRUE	TRUE	FALSE	FALSE	TRUE	TRUE	TRUE	FALSE
Maternal disorder incident case count	TRUE	CONDITIONAL (for validation only and then can be removed)	FALSE	FALSE	TRUE	TRUE	TRUE	FALSE
YLLs and YLDs (cause-specific)	TRUE	TRUE	FALSE	FALSE	TRUE	TRUE	TRUE	FALSE
Severity-specific maternal hemorrhage incident case count	TRUE	CONDITIONAL (for validation only and then can be removed)	FALSE	N/A	TRUE	TRUE	TRUE	FALSE
Sum of maternal hemoglobin exposure values	TRUE	TRUE	FALSE	TRUE	TRUE	TRUE	TRUE	FALSE
Anemia state person-time	TRUE	TRUE	FALSE	TRUE	TRUE	TRUE	TRUE	TRUE
Maternal intervention counts	TRUE	FALSE	FALSE	FALSE	FALSE	FALSE	FALSE	CONDITIONAL (for validation only and then can be removed)

Outputs needed to inform the children under five simulation:

The following ouputs should be a table including the following data for each live birth that occurs in the maternal simulation:

• Input draw

• Scenario

• Random seed

• Date of birth

• Infant sex

• Joint categorical maternal BMI/anemia exposure

• Birthweight exposure (either as sampled from GBD or post-adjustment due to the correlation between maternal anemia/BMI and birhtweight, in which case we would not need the joint categorical maternal BMI/anemia exposure above)

• Gestational age exposure

• Maternal supplementation coverage

• Maternal antenatal IV iron coverage

• Maternal postpartum IV iron coverage

• Birthweight shift due to intervention coverage (NOTE: alternatively, this may be calculated in the child simulation from reported maternal intervention coverage values)

5.0 Back of the envelope calculations

6.0 Limitations
